Magnum 6K16V Managed Fiber Switch Installation and User Guide (01/04)
5
www GarrettCom com
.
.
GBPM-COTX
One Gigabit module, uses one 6K16V slot and provides one GBIC open
transceiver port for a user selectable GBIC connector module
GBIC-SXSC
GBIC transceiver module for use in GBPM-xOTX, one SX port with
mm SC fiber connector
GBIC-LXSC
GBIC transceiver module for use in GBPM-xOTX, one LX port with
mm SC fiber connector
GBIC-LXSC10 GBIC transceiver module for use in GBPM-xOTX, one LX port with
Single mode SC (10km) fiber connector
CONSOLE CBL Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable) to connect to a managed
switch, and a USB port to connect to a PC
DIN-RAIL-VRM Set of two DIN-Rail holders for a secure vertical mount of a 6K16V
unit, with screws to attach to metal mounting brackets and to the 6K16V case.
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
