Magnum 6K16V Managed Fiber Switch Installation and User Guide (01/04)
3
www GarrettCom com
.
.
For DC internal power supplies at –48VDC, 24VDC and 125VDC,
including Dual Source options (
for continuity of operation when either of the
DC input sources are interrupted)
, see Appendices B and C.
Per-port jumpers and switches
The copper daughter board has on internal switch for selecting MDI-MDIX
crossover on port # 1. Factory default setting is MDI, user port.
Other port-specific user settings ( such as FDX or HDX, copper 10/100 speed)
can be fixed using software commands.
Agency Approvals
UL listed (UL60950), cUL, CE
Emissions meet FCC Part 15 Class A
IEEE P1613 Environmental Standard for Electric Power Substations
Warranty: Three years, per UL 60950 temperature rating
Made in USA
NEBS Test Classification: NEBS Compliant
for details.
