4-47
(10)Sheet guide assembly
No.
1
2
3
Location
Sliding section
Sliding section
Boss (four places)
Remarks
Wipe off excess oil after applying
Wipe off excess oil after applying
Wipe off excess oil after applying
Amount
C
C
C
Oil
SG
SG
SG
2-SG-C-O
Sheet guide
1-SG-C-O
40 mm
4 mm
6 mm
Stopper L
3-SG-C-O
3-SG-C-O
Stopper R
Sheet guide R
Sheet guide L
(2-SG-C-O)
(1-SG-C-O)
