Genicom MatrixPrinter LA36 - Manual (Page 76)

4-40
(3) LF gear bearing and continuous/single lever
No.
1
2
3
4
Location
Gear teeth (4 places)
(Gear A, B, C, D)
Gear bearing (4 places)
(Gear A, B, C, D)
Gear surface
Gear holder boss
Remarks
Shaded portion
Amount
C
C
C
C
Oil
SG
SG
SG
SG
4-SG-C-0
2-SG-C-0
Motor bracket
Y401
Gear A
Y421
Gear holder
Y410
3-SG-C-0
Gear C
Y425
Gear B
Y422
1-SG-C-0
Gear D
Y424
