4-2
4.3 4.3 4.3 4.3 4.3 Maintenance Tools Maintenance Tools Maintenance Tools Maintenance Tools Maintenance Tools
Table 4.1 lists the tools required for maintenance.
Table 4.1 Maintenance tools
No
1
2
3
4
5
6
7
8
9
10
Tool
Screwdriver M3–M5 (+)
Screwdriver M2–M2.5 (+)
Screwdriver M3–M4 (–)
Tweezers
Spring hook
Long-nosed pliers
Thickness gage (0.03 ~ 1mm)
Platen gap adjustment gauge
Silicone grease
Floil
Type or part number
Phillips (*1)
Phillips (*1) (*2)
Standard (*1) (*3)
CWZ9068A2 (*3)
CWZ9070A
CWZ9248A
CWZ9250A
CA02312-F300
CA98001-5270
D89L-1020-0369
Maintenance level
2
2
2
2
2
2
2
2
2
1
*1 A magnetized driver is convenient.
*2 For removing the RS-423 board and the card guide sensor cable holder.
*3 For fitting the E-ring. (Tweezers are convenient, but standard screwdrivers are available.)
4.4 4.4 4.4 4.4 4.4 Maintenance Levels Maintenance Levels Maintenance Levels Maintenance Levels Maintenance Levels
Maintenance for the LA36N/LA36W printer is done at two levels.
• Level 1 maintenance includes cleaning and lubrication.
• Level 2 maintenance includes level 1 items, plus replacement of PC boards, units, and mechanical
subassemblies, and adjustment after replacement.
4.5 4.5 4.5 4.5 4.5 Preventive Maintenance Preventive Maintenance Preventive Maintenance Preventive Maintenance Preventive Maintenance
No periodic maintenance is required. However, keeping the printer clean lengthens its service life and MTBF.
