5-13
c.
Continuous forms fed via pull tractor from the bottom slot
Paper end is detected by feeler 3 linked to sensor C (detailed in Figure 5.12).
It is approximate 35 mm from the print position.
d.
Continuous forms fed via pull tractor from the rear side
Paper end is detected by feeler 3 linked to sensor C.
Continuous forms
Pull tractor
Feeler 3
Feeler 1
Figure 5.13 Paper end detection (continuous forms via pull-feed tractor)
