Chapter 1 ETERNUS VSS Hardware Provider
1.3 Operational Procedure

ETERNUS VSS Hardware Provider 2.1 User’s Guide

Copyright 2012 FUJITSU LIMITED

P3AM-4582-03ENZ0

22

The following shows examples of both a single active production server, single standby production
server case (1:1), and for a multiple active production server, single standby production server case
(n:1).

-

Example of 1:1 case

-

Example of n:1 case

Windows Server

(active production

server)

Windows Server

(standby production

server)

Windows Server

(backup server)

ETERNUS Disk
storage systems

Guest OS

Disk

Shadow Copy

Destination

Windows Server

(active production

server)

(work 1)

Windows Server

(standby production

server)

(work 1)
+
(work 2)

Windows Server

(backup server)

ETERNUS Disk
storage systems

Guest OS

Disk

(work 1)

Guest OS

Disk

(work 2)

Shadow Copy

Destination

Windows Server

(active production

server)

(work 2)

Shadow Copy

Destination
