96 Operating Manual RX600 S6
CSS components
©
c
og
ni
ta
s.
Ges
el
ls
ch
ft f
ü r T
e ch
ni
k-
D
ok
um
e
nt
a tio
n m
bH
201
1
P
fad:
C:
\P
rog
ra
m
m
e\
F
C
T
\ti
m
_a
pp
\ti
m
_l
o
ca
l\w
or
k\
P
ICH
OL
\O
B
J_
D
OK
U
-1
1 94
2-
00
1.
fm
● Always set the HDD/SSD module down carefully, with the large surface
facing downwards to prevent it from tipping over.
8.1.3.1 HDD/SSD module and dummy module
Figure 18: 2.5-inch HDD module and dummy module
1 Dummy module
2 Tabs for unlocking the dummy module
3 HDD/SSD module (installation frame with hard disk drive or solid state
disk installed)
4 Indicators:
HDD/SSD Busy (LED green)
HDD/SSD Fault (LED orange)
For description see section
"Indicators on the hot-plug HDD/SSD
modules" on page 62 .
5 Handle for locking and unlocking the HDD/SSD module
6 Button for locking and unlocking the handle
7 Ridge for applying a sticker with the current drive name and drive size
/ 0 1 23 4 5 0
