RX600 S6 Operating Manual 51
Hardware installation
AC source related power supply configuration and system load limits
The system configuration and load is limited by the number of AC mains power
sources available as indicated in the following table.
Installation in PRIMECENTER/Datacenter rack
Please follow the installation requirements for connection to the mains
described in the rack manuals.
Number
of power
supply
modules
installed AC redundant systems
(requires 2 AC sources) AC non-redundant systems
(connected to 1 AC source)
Max. DC
loading to
support AC
redundancy Installation
requirements Max. DC
loading for AC
non-redundant
systems Installation
requirements
2 830W 2 PSUs
connected to
mains (1+1)
1580W 2 PSUs
connected to
mains (1+1)
3 N/A N/A 2320W 3 PSUs
connected to
mains (2+1)
4 1580W 2 PSUs
connected to
mains2 PSUs
connected to
an isolated AC
source
e.g. UPS (2+2) 2320W 4 PSUs
connected to
mains (3+1)
Table 4: System power supply configuration and system load limits
