RX600 S6 Operating Manual 131
Appendix: server specification
Drive bays
General system information
Operating Panel
Dimensions / Weight
HDD/SSD bay
configuration 8 x 2.5-inch hot-plug SAS/SATA
Accessible drive bays 1 x 5.25/0.5-inch for DVD/DVD-RW/BD
1 x 5.25/1.6-inch for backup devices
Notes accessible drives all possible options described in relevant system
configurator
Number of fans 8
Fan configuration hot-plug
Operating buttons On/off switch
NMI button
Reset button
ID button
Status LEDs Global error indicator (amber / yellow)
ID Indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (green / amber / yellow)
At system rear side:
Global error indicator (amber / yellow)
ID Indicator (blue)
Service display
(optional): ServerView Local Service Display (LSD)
Weight up to 46 kg
Weight notes Weight may vary depending on actual configuration
