3. PLOTTER OPERATION

3-6

3.1.4

Nav data display

The nav data display provides comprehensive navigation data, and it can be
shown in a full-screen display and a combination display. The user may select
what data to display and where to display it. For details see the paragraph “5.8
Nav Data Display Setup.”

Appropriate sensors are required. Bars ( - -) appear when corresponding sensor
is not connected.

ETA

TTG

TRIP LOG

103

nm

TIME

DATE

FEB 1

0

D

2

H

30

M

1st 1:25

01:27:05

2001

POSITION

34

°

34. 5678' N

120

°

34. 5678' W

SOG

WPT POSITION

COURSE

STW

10.0

kt

RANGE

BEARING

9.2

°

M

TEMP

DEPTH

Speed over ground

Position

Water temperature

Range to
waypoint
Course

Bearing to
waypoint

Speed through
water

Waypoint
Position

Depth

Half-screen display

Full-screen display

34

°

14. 5678' N

120

°

14. 5678' W

10.0

kt

101.6

°

M

0.18

nm

1324.1

ft

18.2

°

C

Nav data displays
