Furuno NAVNET 1833 User Manual
Page 13
xi
Two-unit NavNet system
Antenna Unit
GPS Receiver
GP-310B/320B
Radar data
Plotter data
Two-unit NavNet system
Three-or-more-unit NavNet system (Max. 4 NavNet capable display units)
Antenna Unit
GPS Receiver
GP-310B/320B
HUB
Network
Transducer
ETR-6/10N
Sounder data
Radar data
Plotter data
Note: The picture disappears
10 seconds after the NavNet
cable is disconnected from a
"sub" NavNet display unit.
Three-or-more-unit NavNet system
