7. MAINTENANCE, TROUBLESHOOTING


7-5

7.5.4 Sounder

Requires Network Sounder ETR-6/10N.

Sounder troubleshooting

If… But…

Then…

you selected a
sounder display with
the DISP key

picture does not appear

check that the network sounder’s
signal cable is firmly fastened.

Check that sounder source is
correct.

check that the network sounder is
plugged in. The LED of the
network sounder should flash
every second.

marks and
characters appear

picture does not appear

check for loosened transducer
connector.

picture appears

zero line does not appear

the picture is shifted. Confirm the
shift setting.

picture sensitivity is
too low

check gain setting, if using manual
operation.

marine life or air bubbles may be
clinging to transducer face.

bottom may be too soft to return a
suitable echo.

the depth indication
is not displayed

adjust gain and range to display
the bottom echo, if you are using
the manual sounder mode.

noise or interference
shows on the display

check to be sure the transducer
cable is not near ship’s engine.

check the ground.

other video sounders of the same
frequency as yours may be
operating near you.

the water
temperature graph
appears

data is wrong

check that sensor cable is tightly
fastened.
