3. PLOTTER OPERATION


3-47

4. If you selected PORT at step 3, use the trackball to select a port, then press

the ENTER soft key. Make a route using the soft keys, then push the
[ENTER] knob. (If you want to go directly to that port, simply press the ADD
QP soft key followed by the [ENTER] knob.)

If you selected NEAR SRVC at step 3,

select service mark desired with the

trackball, then press the ENTER soft key or the [ENTER] knob. Then, the
display shows the locations of those services nearest you. (The figure below
shows the location of filling stations in an area in southern Italy.) Use the
trackball to place the “hand cursor” on the port service icon desired, then
press the ENTER soft key. Make a route using the soft keys, then push the
[ENTER] knob. (If you want to go directly to location selected, simply press
the ADD QP soft key followed by the [ENTER] knob.)

FROM
OS

0.26 nm
180.2

°

M

PUNTA CORNACCHIA

ACCO AMENO

I. ISCHIA

CASAMICCIOLA

ISCHIA
PORTO

40

°

45.971'N

13

°

57.462'E

+

GOTO

ENTER

CANCEL
GOTO

16.0nm

Sample filling station locations (southern Italy)
