5. CUSTOMIZING YOUR UNIT


5-5

5.2.2 Radar

range

setup

You may choose the radar ranges you wish to use, from the RADAR RANGE
SETUP menu. After choosing the ranges desired, change the range with the
[RANGE] key to activate range settings. Available ranges depends on the radar
used.

At least two ranges (excluding maximum range) must be turned on. When less
than two ranges are turned on, you cannot escape from the RADAR RANGE
SETUP menu.

1. Press the [MENU] key to show the main menu.
2. Press the RADAR RANGE SETUP soft key to show the RADAR RANGE

SETUP menu.

RANGE
SETUP

RETURN

ON/OFF

0.125nm

0.25nm

0.5nm

0.75nm

1nm

1.5nm

2nm

3nm

4nm

6nm

8nm

12nm

16nm

24nm

36nm

48nm

64nm

MAXIMUM RANGE XXnm

*

ON

ON

ON

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

ON

OFF

OFF

RANGE
SETUP

RETURN

ON/OFF

0.25km

0.5km

0.75km

1km

1.5km

2km

3km

4km

6km

8km

12km

16km

24km

36km

48km

64km

ON

ON

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

OFF

ON

ON

OFF

OFF

Range unit: nm

Range unit: km

* = Max. range depends on network radar used and is set on the network radar at installation.

MAXIMUM RANGE XXnm

*

Radar range setup menu

3. Use the trackball to select the range which you want to turn on or off.
4. Press the ON/OFF soft key to turn a range on or off as appropriate.
5. Press the RETURN soft key to register settings.
6. Press the [MENU] key to close the menu.

Model Maximum

Range

1833

36 nm, km, sm

1933

48 nm, km, sm

1943

64 nm, km, sm
