1. OPERATIONAL OVERVIEW

1-13

1.5.4

Selecting image source

When more than one network radar or network sounder is connected to the
equipment, you may select an image source for each as shown below. This is
not necessary when only one network radar or network sounder is connected.

1. Press the [DISP] key.
2. Press any soft key to show the following display.

RADAR SOURCE
RADAR - - -
SOUNDER SOURCE
SOUNDER -
IP APPRESS
172. 031. 003. 002

HOST NAME
RADAR - - -

SELECT
SOURCE

EDIT

RETURN

IF THERE IS MORE THAN
ONE NETWORK RADAR OR
ECHO SOUNDER, YOU MAY
SELECT THE IMAGE
SOURCES FOR DISPLAY.

Select source menu

3. Use the trackball to select RADAR SOURCE or SOUNDER SOURCE as

appropriate, then press the EDIT key.

RADAR SOURCE

SOUNDER SOURCE

Radar source Sounder source

R

ADAR - - -

S

OUNDER-

Radar source and sounder source windows

4. Adjust the trackball to select location and rotate the [ENTER] knob to set

character.

5. Push the [ENTER] knob to set.
6. Press the [DISP] key to finish.
7. Turn the power off and on again.

Note: Source names are determined at installation. For example, the source

names for radars in a two radar system might be “RADAR” and
“RADAR1”.
