5-27
SM Symbol mode on/off. Plot the specified character (marker) at each end of vectors.
SP Select a logical pen.
SV Specify the screened vector, or the type of a image pattern imposed on lines.
TR Transparency mode on/off. With mode on, the background is visible through
blank areas of the foreground.
UL User-defined line type. Create a type of line which is substituted for a line type
defined by the LT command.
WU Select the unit of pen width for the PW command.
Character Plotting Commands
AD Define characteristics of the alternate font.
CF Specify an outline character fill mode and whether or not characters are to be
edged (outlined).
CP Character plot. Move the logical pen by the specified numbers of character cells
(character spaces and lines).
DI Set the direction (inclination) of characters relative to the absolute plotter
coordinates.
DR Set the direction (inclination) of characters relative to the scaling points P1 and
P2.
DT Define a terminator character that specifies the end of printing a character string
in label mode.
DV Define variable text path. Set the plotting direction of a character string in 90
degrees and set the direction of line feeding.
ES Extra spaces. Increase or decrease the character spacing and line spacing.
FI Font primary. Specify the font, to which the font ID is assigned in PCL mode,
as the standard font.
FN Font secondary. Specify the font, to which the font ID is assigned in PCL mode,
as the alternate font.
LB Label mode. Plot a character string using the current active font.
The following control characters are available. Other characters are NOP
commands.
ETX
BS
HT
LF
CR
SO
SI
SP
DEL Default of terminator character
Back space
Double space
Line feed
Carriage return
Alternate character set selection
Standard character set selection
Space
Space
Char Function
LO Label origin. Move the origin of plotting a character string in label mode.
