FUJITSU fi-5950 - Manual (Page 252)

232
10.2 Installation Specifications
10.2 Installation Specifications
Item Specification
Dimensions
(With hopper and stacker retracted) Depth Width Height
540 mm,
21 in 540 mm,
21 in 500 mm,
20 in
Space requirements
Weight (kg) 50 kg (110.4lb)
Input power Voltage AC100 - 240 V±10%
Phase Single-phase
Frequency 50/60 Hz ±3Hz
Power consumption 250 W or less
Ambient condi-
tion Device status Operating Not operating
Temperature 15 to 35 degrees
Celsius
59 to 95 degrees
Fahrenheit -20 to +60 degrees
Celsius
-4 to +140 degrees
Fahrenheit
Humidity 20 - 80% 8 - 95%
Heat capacity Operating 216 kcal/Hr or less
Not operating 113 kcal/Hr or less
Power Saving TWAIN/ISIS : 5.2 kcal/Hr or less
VRSIF : 6.05 kcal/Hr or less
Total Package Weight (kg) 70
600 mm
(23.62 in)
200 mm
(7.874 in)
600 mm
(23.62 in)
Front
Scanner
200 mm
(7.874 in)
