Page 73
63
Power supply/frequency
Power consumption
Mass
Outside dimensions
(vertical placement)
Operating environment
230V AC, 50/60Hz
132W maximum
Approx. 9.5kg
105mm x 388mm x 356mm (W x D x H)
Temperature: 10 to 35°C, Humidity: 20 to 80% (RH)
*1:
Disk capacities are based on conversion of 1 MB = 1000 2 bytes and 1 GB = 1000 3 bytes. Actual disk capacities based on
conversion of 1 MB = 1024 2 bytes and 1 GB = 1024 3 bytes are displayed on Windows as smaller than those described on this
manual.
Point
• For improvement, the specifications of products are subject to change without notice.
LAN adapter specifications
LAN controller
RAM for send/receive buffer
External interface
Transfer media
Transfer method
Access method
Data transfer speed
Wiring shape
Maximum segment length
Maximum number of nodes per segment
Built-in Intel 82801BA 10/100 Mbps Bast-T
(Wake-on LAN and Alert-on LAN Supported)
3 kilobytes each for sending and receiving
ISO8802-3 100BASE-TX/10BASE-T
Twisted-pair cable
*1
(100 Mbps: Category 5, 10 Mbps: Categories 3 to 5)
Base band
CSMA/CD
100 Mbps, 10 Mbps
Star shape
100 m
Depending on the hub unit
*2
*1:
To ensure network operation at 100 Mbps, use an unshielded twisted-pair (UTP) cable in Category 5 or higher data grade. Use
of Category-3 cable will cause data loss.
*2:
A hub unit is a 100BASE-TX/10BASE-T concentrator.
Point
• The LAN installed to the PC as a standard feature adjusts automatically to the network speed.
If the network speed changes due to changes in the hub unit, be sure to use cables of an ap-
propriate data grade for that speed.
