Inside the pc unit – FUJITSU 500 User Manual
Page 17
6
Inside the PC unit
1
2
3
4
1
Internal hard disk drive
This is an IDE-compliant hard disk drive.
2
Expansion card slots
Insert an expansion card to this slot.
This slot accommodates a PCI card.
A SCSI card allows you to use an external hard disk drive or magneto-optical disk drive.
Note that this PC does not support internal SCSI options.
3
Power supply unit
4
3.5-inch front access bay
An internal IDE option (for example, magneto-optical disk drive) can be installed.
