Example of installation
Install your PC as shown in the figures below.
The PC unit can be installed either vertically or horizontally. Pay attention not to block the ventholes
on the back of the PC unit.
Vertical placement
Foot
Horizontal placement
You can place a display (17 inches or smaller, weighing 19 kg or less) on the PC unit.
Point
• The remaining part of this manual assumes vertical placement. When you place the PC unit
horizontally, be careful about geometrical difference.
PC unit
Display
Mouse
Keyboard
Foot
PC unit
Display
Mouse Keyboard
