42

Installing an Expansion Card

1

Unplug the PC.

2

Remove the upper cover.

3

Remove the mounting bracket.
Pull up the mounting bracket vertically.
When an expansion card has been installed, remove the cable from the card and remove the
bracket.

4

Remove the slot cover.
Remove the screw from the position where the expansion card is installed, and remove the slot
cover.

Point

• Keep the removed slot cover.

Use the cover to keep an empty slot from dust.
