47
Installing Other Internal Options
Installing a device in the 3.5-inch front access bay
This section explains how to install an internal option such as a 3.5-inch hard disk drive or magneto-
optical disk drive to your PC. Here is an example of installing a magneto-optical disk drive.
1 Make a setting on the option to be installed.
Refer to the manual for the option and make a Master/Slave/Cable Select setting.
2 If brackets are attached to both sides of the internal option to be installed, remove the
brackets.
Remove the four screws to remove the brackets.
3 Unplug the PC.
4 Remove the upper cover.
5 Remove the reinforcement bracket.
6 Remove the blank panel.
