50
10 Connect the power cable.
Connect a power cable to the connector on the installed internal option.
11 Reinstall the reinforcement bracket.
12 Reinstall the upper cover.
When necessary, remove the blank panel of the 3.5-inch front access bay from the back of the
upper cover as shown by the arrow in the figure.
Do not remove the blank panel when installing a hard disk drive.
Stopper Press
down to remove
Point
• For removal, use the installation procedure in the reverse order.
• After installing a hard disk drive or magneto-optical disk drive, take the following steps to con-
figure the disk drive.
- Windows Me/98/95 models
When you have installed a hard disk drive, from MS-DOS prompt on the Start menu, use the
FDISK command to configure sectors. Then, format the additional hard disk from My Com-
puter.
- Windows 2000 models
When you have installed a hard disk drive, configure sectors and format the disk by using
Administrate the Disk. Administrate the Disk is under the Storage Area displayed by clicking
the [Start] button, [Program], then [Administrate the Computer].
- Windows NT models
When you have installed a hard disc drive, configure sectors and format the disk by using
Disk Administrator. Disk Administrator is activated by clicking the [Start] button, [Program],
then [Administration tools].
• Keep the removed brackets.
