4.3
Interface Registers
4.3.1
I/O registers
This section provides the I/O register functions and mapping. Definitions of each register vary
depending on which ATA or ATAPI commands are used.
Table 4.4
I/O port functions and mapping
Address signal
Function
CS0-
CS1-
DA2
DA1
DA0
READ (DIOR-)
WRITE (DIOW-)
N
N
x
x
x
High impedance state
Ineffective
Control block register
N
A
0
x
x
High impedance state
Ineffective
N
A
1
0
x
High impedance state
Ineffective
N
A
1
1
0
Alternate Status
Device Control
N
A
1
1
1
Device Address
Ineffective
Command block register
A
N
0
0
0
Data
A
N
0
0
1
Error
ATA Features (ATA)
ATAPI Features (ATAPI)
A
N
0
1
0
Sector Count (ATA)
ATAPI Interrupt Reason
(ATAPI)
Ineffective
A
N
0
1
1
Sector Number
A
N
1
0
0
Cylinder Low (ATA)
ATAPI Byte Count (bits 0-7) (ATAPI)
A
N
1
0
1
Cylinder High (ATA)
ATAPI Byte Count (bits8-15) (ATAPI)
A
N
1
1
0
Device/Head (ATA)
ATAPI Block Device Select (ATAPI)
A
N
1
1
1
ATAPI Status
ATA Command
A
A
x
x
x
Ineffective
Ineffective
The letter A indicates that the bit is asserted, N indicates that the bit is negated, and X indicates
that the bit is ignored.
