2.2.2 Optical disk cartridge
Figure 2.1 shows an optical disk cartridge. The figure below shows the cartridge with its shutter
open.
$ Shutter closed
$ Shutter open
Figure 2.1 Optical disk cartridge
4) Disk
5) Hub
3) Write protect tab
1) Cartridge case
2) Shutter
