C156-E142-02EN 4 - 3
Table 4.2 Connector pin assignments (2/2)
Description PIN Signal name
DMA Acknowledge 29 DMACK-
Gound 30 Ground
Interrupt Request 31 INTRQ
16 Bit I/O 32 IOCS16-
Device Address Bit 1 33 DA1
PASSED DIAGNOSTICS 34 PDIAG-
Device Address Bit 0 35 DA0
Device Address Bit 2 36 DA2
Chip Select 0 37 CS0-
Chip Select 1 38 CS1-
Device Active or Slave (Device 1) Present 39 DASP-
Ground 40 Ground
