C156-E142-02EN 5 - 7
5.3 Optical Disk Cartridge Operation
5.3.1 Optical disk cartridge
Figure 5.4 shows the optical disk cartridge. For operation and cleaning, users should be familiar
with the parts shown in the figure.
See Subsection 2.3.2 for the functions of the parts.
! Shutter closed
! Shutter open
Figure 5.4 Optial disk cartridge
5. Hub
4. Disk
3. Write protect tab
1. Cartridge case
2. Shutter
