5 - 12
C156-E142-02EN
Damage for disk medium
At setting the cartridge to the setting case, do not apply the heavy shock
and push hardly.
3) Cover the cartridge with the setting case cover, then insert the spindle pin into the center hub
of the cartridge.
Figure 5.8
Cleaning procedure (3)
4) Remove a slender piece that causes a defect from the disk surface at wiping the disk media.
5) Moisten the cleaning cloth with a few drops of cleaning solution.
Eye inflammation
In case of contact with eyes, immediately flush eyes with water.
6) Wipe the disk surface from the hub outward.
Cartridge opening
Disk media
Disk hub
Setting case cover
Revolver
