4 - 76 C156-E142-02EN
Table 4.114 Register/PIO data transfer timing parameters
Symbol Timing parameter min
(Units: ns)
max
(Units: ns)
Condition
t0 Cycle time 120 - At mode 4, no wait
t1 Address valid to DIOR-/DIOW- setup 25 -
t2 DIOR-/DIOW- pulse width 70 -
t2i DIOR-/DIOW- recovery time 25 -
t3 DIOW- data setup 20 -
t4 DIOW- data hold 10 -
t5 DIOR- data setup 20 -
t6 DIOR- data hold 5 -
t6Z DIOR- data tristate - 30
t7 From address decided to IOCS16 asserted - 30
t8 From address decided to IOCS16 released - 30
t9 DIOR-DIOW- to address valid hold 10 -
tA IORDY setup time - 35 PIO flow control
transfer mode
tB IORDY pulse width - 1250 PIO flow control
transfer mode
tRd Read data valid to IORDY active 0 -
