3 - 2

C156-E142-02EN

(a) Inside optical disk cartridge

(b) IC (controller, read map)

Figure 3.1

Surface temperature measurement points

Hole for inserting thermocouple

IC (controller)

IC (read amp)

Tip of thermocouple

Operating of inner
partition wall
