ReDAQ
®
Shape Software for MAQ
®
20 User Manual
12
The following documents are available from Modbus IDA (
HU
www.modbus.org
UH
):
• Modbus Application Protocol Specification
• Modbus over Serial Line Specification & Implementation Guide
• Modbus Messaging on TCP/IP Implementation Guide
The following Tools and documents are available from FieldTalk (
HU
www.modbusdriver.com
UH
):
• Modbus Protocol Drivers and DLL Libraries
• FieldTalk User Manual
The following Tools and documents are available from National Instruments (
HU
www.ni.com
UH
):
• Free Modbus Protocol Drivers VI ’s and Examples
• LabVIEW User Manual
• Measurement Studio User Manual
2.0 ReDAQ
®
Shape for MAQ
®
20 Integrated Development Environment
2.1 Start Window
After starting ReDAQ
®
Shape for MAQ
®
20, the setting dialog box will be displayed for selecting settings,
configurations of development environment and parameters. The user can select the previous project
settings [OK] or the MAQ
®
20 system default settings [Cancel].
The Interactive Development Environment (IDE) of ReDAQ
®
Shape for MAQ
®
20 provides a user friendly
and comprehensive interface with easy to use pull down menus, convenient toolbars, and three
development panels [Acquire-Analyze-Present], which provide easy methods to setup, configure and
operate the MAQ
®
20 Data Acquisition System. Users can develop application specific interfaces,
projects, and automatic control loops to process, analyze, and acquire data.
