ReDAQ
®
Shape Software for MAQ
®
20 User Manual
61
6.2.2 Demonstration Project #2: Gauge Tool Interface to Input Channel
Filename Demo_Gauge.rsd or Demo_Gauge.rsu
A Gauge Tool is assigned to analog input channel.
The output of an analog channel has been scaled to 0
– 120 and the Gauge Tool has
also been scaled to 0
– 120.
Apply a voltage of 0-5V to the input of channel. The Gauge Tool will show the respective
speed.
