CAUTION:

After removing an expansion card, you must replace it with a new card or expansion

slot cover for proper cooling of internal components during operation.

To install a new expansion card, slide the card under the slot cover retention latch and press the
card down into the socket on the system board.

NOTE:

When installing an expansion card, press firmly on the card so that the whole connector

seats properly in the expansion card slot.

Rotate the slot cover retention latch back in place to secure the expansion card.

10.

Connect external cables to the installed card, if needed. Connect internal cables to the system
board, if needed.

11.

Replace the access panel.

12.

If necessary, reconfigure the computer. Refer to the Computer Setup (F10) Utility Guide for
instructions on using Computer Setup.

Expansion Cards 123
