3-8 P/N 480-0005-00-15
Chapter 3: Installation
Connect to Ethernet LAN (with CPU Card)
You can use these instructions for general connection purposes only. The Ethernet hub/switch manufacturer
documentation should provide specific instructions for connection to another device, such as Tenor CMS. One
Ethernet port is enabled; the other three ports are not used.
NOTE: For illustrations purposes, the unit is shown with CMS240 (2 slot) with AC power.
Figure 3-5 Connect to Ethernet Hub/Switch
1. Plug one end of the grey RJ-45 ethernet cable into one of the ports on the CPU rear transition module
labeled 10/100 Ethernet.
2. Plug the other end of the cable into the Ethernet hub/switch port. If a custom cable or adapter is required,
see Chapter 2: Hardware Components for Ethernet RJ-45 10/100.
Data
Network
Ethernet Hub/Switch
Chassis Rear (AC view)
10/
1 0 0
Et
h
e rn e t 1 2 3 4 5 6 7 8
DS1 Li nk
TX/ R X
Li nk
TX/ R X
CP
U
2
4
8
3
7
26 15
TX
/R
X 1 2 3 4
Li nk Co
n
fig
1 2 3 4
Of
f
On C o ns
ol
e
10/ 1 0 0
Et
h
e rn e t
1
0
CP
U
2
4
8
3
7
26 15
TX
/R
X 1 2 3 4
Li nk C onf
ig
1 2 3 4
Of
f
O
n
Cons
o le
10/
10
0 Et
h
e rn
e t
