3-90-775R15_04/13

Service Parts

P35i Pellet Insert

Beginning Manufacturing Date: July 2010

Ending Manufacturing Date: Active

IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement

parts for your appliance please provide model number and serial number. All parts listed

in this manual may be ordered from an authorized dealer.

Stocked

at Depot

ITEM

Description

COMMENTS

PART NUMBER

21

Cleanout Cover Set

Left & Right

1-00-774213

22

Combustion Blower

3-21-08639

Y

Combustion Blower Mounting Screws

Pkg of 100

1-00-53483208

23

Combustion Blower Mount

1-10-677006

24

4-3/4 Single Paddle Blade

3-21-00661

Y

25

Combustion Cleanout

1-10-774167A

Y

26

Distribution Blower

1-00-29145

Y

27

UL Feeder Assembly

See following page

14 Ft Power cord

3-20-674200

Y

306W/120V Igniter 15 Fin

3-20-677200

Y

Pkg of 10

1-00-677200

Y

Airwash O-rings

Pkg of 10

1-00-939639

Y

Ash Lip Trim

Gold

3-43-08400

Brushed Stainless 3-43-08400-7

Bright Nickel

3-43-08400-8

Burnpot Scrapers

Pkg of 10

2-00-773850-10

Diagnostic Display Module

3-20-05401

Y

DDM Replacement Cable

1-00-05402

Disconnect, 3/16" Female

Pkg of 25

1-00-08529

Y

Disconnect, Female

Pkg of 25

1-00-00959

Y

Disconnect, Male

Pkg of 25

1-00-00957

Y

Door Hinge

2-00-06707L

Door Trim

Gold

3-43-06717-4

Brushed Stainless 3-43-06717-7

Bright Nickel

3-43-06717-8

Draft Meter Assembly

1-00-00637

Y

Draft Meter Bolt & Tube

1-00-04004

ESP-RED/RED

3-20-00844

Y

Labels, Caution & Danger

10 Sets

1-00-200408541

Lintel, All Thread

Qty 2 req

3-31-00949

Pipe Insulation

3-44-774282

Y

Pop Rivets, 1/8" Black

Pkg of 100

3-30-1104-100

Y

Roller Hardware

4 Sets

1-00-05232

Y

Room Sensor

3-20-00906

Y

Touch up Paint, Black

12 oz Can

3-42-1990

Wiring Harness

3-20-08727

Y

Additional service parts on following page.
