10
P35i Fireplace Insert
Pellets or Corn/Pellet Mixture Only Save These Instructions 3-90-775R15_04/13
C. Floor Protection Requirements
Hearth extension must be of a non-combustible material.
It must extend beyond the appliance according to the
measurements listed.
Minimum Size Hearth Extension is 16" Deep By 32" Wide.
C
D
B
A
Location Inches Millimeters
Insert to combustible sidewall
Surround top to face trim
13 330
1 25.4
0 0
12 305
Surround side to face trim
Insert top to (max) 12" mantel
F
E
Location Inches Millimeters
Window opening to front 6 152
6 152 Window opening to side
D. Minimum Opening for Masonry
and Manufactured Fireplaces
I
I
H
G
Location Inches Millimeters
Minimum Width 24 609
23½ 597
14.5 368
19½ 495
Minimum Depth
Minimum Height #1-70-774235
Minimum Height #1-70-774195
H
I
G
The Maximum mantel depth (J) is 12 inches (305 mm) with
a minimum vertical height (K) of 12 inches (305 mm).
K
J
E. Mantel Projections
B. Clearances To Combustibles -
Masonry or Manufactured Fireplace
The clearances specified are for your
safeTy! These clearances may only
be reduced by means approved by The
regulaTory auThoriTy.
Mantel
Side W
all
Face Trim
A
B
C
E
D
F
