Series 2040 Test System
Series 2040 Maintenance Manual V2.00 Module Repair and Replacement
61
CIRCUIT BOARD REPLACEMENT
The illustration below shows the positions of the boards in a typical Series
2040 Test System. The MDE, TMS, and AMS are always the last three on the
left side of the tester (as viewed from the rear of the Testhead) and are
dedicated to those slots shown. The PSD (Power Supply Distribution)
assembly always occupies Slot 0, while the PSC (P/S Controller) occupies its
own slot on the far right.
To remove a circuit board, grasp the white tabs on the corners of the board
and spread them outward towards the sides of the Testhead, as shown on the
next page.
PSC
23 22 21 20 19 18 17 16 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 24 25 26
