Series 2040 Test System

Series 2040 Maintenance Manual V2.00

Module Repair and Replacement

52

INTERNAL AND PATCHBOARD POWER SUPPLY OVERVIEW

The Testhead Power Supply Controller monitors Testhead power supplies for

overvoltage with OVP crowbar IC’s. When an overvoltage is detected, the

OVP IC quickly short circuits the offending power supply. This produces an

undervoltage state on that power supply. This is, in turn, sensed by an opto-

isolated comparator to produce a digital fail signal. This digital signal is latched

in the control circuit and removes the AC line power from the Testhead

Internal and/or Patchboard Power Supplies. The state of all comparators is

indicated by the LEDs mounted on the top edge of the controller circuit card.

An illuminated LED in the power supply group indicates a normal condition.

The “PBON”, “RESET”, “PROX” and “EXTERNAL FAULT” LEDs, when all are

illuminated, indicate that power is applied to the patchboard. The

extinguishing of any LED shows the reason for the loss of power to the

Patchboard and/or the Testhead. A dedicated power supply on the controller

circuit card maintains its function without regard to the monitored supplies.

The result of the logical OR of any Testhead Internal Power Supply failure is

logically OR’d with any Patchboard Power Supply failure. The result of this is

provided as a current loop signal through an opto-isolator to the UUT Power

Supply Controller. Therefore, when a fault is detected in the Testhead Internal

Power Supply, all power supplies are shut down. If the fault originates in the

Patchboard Power Supply, the Testhead Internal Power Supply remains on.

The Testhead Power Supply Controller also responds to three external logic

signals. They are the Patchboard Open Sensor, CPU ON/OFF command and

Reset. A proximity detector, located near the Patchboard, senses the release of

the Patchboard and causes a shutdown of the Patchboard Power Supplies,

and indirectly the UUT Power Supplies. The CPU ON/OFF command (see the

functional call POWER) is a programmed command where a “0" causes the

Patchboard Power Supplies to shut down without a detected fault condition.

A ”1" enables the Patchboard Power supplies. The Patchboard Power is

removed when a Testhead reset is issued. (See the TCLEAR functional call in

the Programming Manual). When the Patchboard Power Supplies are shut

down, they are also disconnected from the Patchboard via relays.
