Page 61
Series 2040 Test System
Series 2040 Maintenance Manual V2.00
Module Repair and Replacement
60
UUT - GPIB/HPIB POWER SUPPLY DISCONNECT AT TEST BAY
From top to bottom:
PS0
PS1
PS2
PS3 - Jumper
PS4 - Jumper
All unused power supplies must be jumpered. This is a typical installation.
Individual systems may vary. Also note, the GPIB/HPIB power supplies may be
externally connected to the fixture/UUT.
