Panasonic TH-65SQ1WA 65" Class 4K HDR Commercial Monitor - Manual (Page 45)

45
English
Adjusting Position
1 Press to display the
[Position] menu.
0
0
0
0
15
0
Position
Default Default
Auto setup
H-position
H-size
V-position
V-size
Clock phase
Dot clock
PC auto setting Off
Over scan Off
2 Select the item to adjust with .
● Unadjustable items are greyed out.
Adjustable items differ depending on the signal,
input and the display mode.
3 Adjust with .
4 Press to exit from adjust
mode.
■
To return to the previous screen
Press .
■
To reset to defaults
When [Default] is selected, pressing resets
the adjustment values of all the displayed menus to
default.
When adjusting each item, pressing
resets the adjustment value of the item to default.
Note
● When using Screen Transfer input, [Position] cannot
be set.
● Settings for [Position] are memorised separately for
each input signal.
Setting [Position] when [Image rotation] is set to
[180 degrees]
When [Image rotation] is set to [180 degrees], the
adjustment direction becomes opposite of that in [Off]
state. (see page 87)
Note these points for adjustment.
Auto setup
When inputting a PC signal, [H-position] / [V-position],
[H-size] / [V-size], [Clock phase] and [Dot clock] are
automatically corrected.
This setting is enabled under the following
condition:
● This setting is enabled when an analogue signal
(PC) is input and the aspect mode is set to [Full].
(see page 90)
While displaying the picture of the corresponding
signal, select [Auto setup] and press .
Using Remote Control
Press .
When Auto Setup does not work, [Invalid] is
displayed.
Note
● When the dot clock frequency of a PC signal is 162
MHz or higher, [Clock phase] and [Dot clock] cannot
be automatically corrected.
● Auto Setup may not work when a cropped or dark
image is input. In such case, switch to a bright image
with borders and other objects are clearly shown, and
then try auto setup again.
● Depending on the signal, out of alignment may occur
after Auto Setup. Carry out fine tuning for the position/
size as required.
● If the automatic position adjustment is not optimized
depending on the signal, switching the [Input
resolution] (see page 61) setting may be able to
perform the automatic position adjustment properly.
● Accurate auto setup is not possible when a signal
such as additional information is superimposed out
of valid image period or when intervals between
synchronizing signal and image signal are short.
Also, accurate auto setup is not possible when image
signals with tri level synchronizing signal added are
input.
● When [PC auto setting] is set to [On], automatic
position adjustment starts under the following
conditions:
• When the display power is turned ON.
• When the input signal is switched.
● If Auto Setup does not work well, select [Default],
press , and then adjust the position/size
manually.
