30
English
AUDIO OUT terminal connection
Note
● Audio equipment and the cable shown are not
supplied with this set.
line-in
Stereo mini
plug (M3)
Stereo audio cable (commercially available)
Audio equipment
Note
● To output sound from AUDIO OUT terminal of the
unit, be sure to set [Output select] in the [Sound]
menu to [AUDIO OUT]. (see page 47)
USB terminal connection
Connect the USB memory (commercially available) to
use “USB media player” or “Memory viewer”. (see page
111, 123)
Also, power is supplied when a separately sold stick PC,
etc. are connected.
Note
● A stick PC and connection cables are not supplied
with this unit.
● If the power is turned off or the USB memory device
is removed while accessing data in the USB memory
device, the stored data may be destroyed. The
access indicator of the USB memory device blinks
during data access.
● The USB memory device can be connected or
disconnected whether or not the display is on.
Stick PC (commercially available)
USB cable (commercially available)
HDMI extension cable (commercially available)
When the picture is displayed, depending on the USB
terminal, power of up to 5V/2A (far side terminal)
or 5V/1A (front side terminal) can be supplied to an
external device.
● If the electric current exceeding the power supplying
capability is applied, the output is blocked, and the
following message is displayed.
[USB DC5V OUT overload. Please remove cable or
equipment, then turn the display off/on.]
In this case, remove the equipment and then turn the
power off/on using the remote control, etc.
Note
● Select the USB terminal to be used with [USB select].
(see page 90)
● If the direct connection to this unit is not possible due
to the size of a stick PC, etc. use a commercially sold
extension cable.
● Depending on the type of a USB memory device,
it may come in contact with the periphery such as
a back cover, and cannot be attached. Use a USB
memory device connectable to this unit.
● When connecting the USB memory device, confirm
the orientation of the plug to prevent damage to the
terminal.
