KP915GV Product Manual
111
B Control
Registers
Notes
• The following abbreviations are used in register descriptions:
R=Read RO=Read only R/W=Read/Write W=Write only
• The MSB (Most Significant Bit) is listed first.
B.1 Index
Register
7 6 5 4 3 2 1 0
Version Index
RO RO RO RO R/W R/W R/W R/W
I/O location:
062h
Default:
vvvv
1010b
Version
A read-only field containing the software version number for the logic.
0001 Version
1
0010 Version
2
Index Value
description.
0000 Watchdog
Control
0000 Watchdog
Kick
0000 Watchdog
Status
0001
Watchdog Timeout Period
0010
General Purpose I/O Port 1
0011
General Purpose I/O Port 2 and Control
1000 PWM
Control
1001
Part Number, low digits
1010 Processor
Identification
1011
Part Number, high digits
B.2
Watchdog Control
7 6 5 4 3 2 1 0
Prescale RES
SMI
WEN
0
W W W W W W W W
I/O location:
066h
Index:
0
Default:
00000000b
