Reference DFNT ♦ ProLinx Gateway
Protocol Manual EtherNet/IP Explicit Messaging Client/Server
Page 82 of 124 ProSoft Technology, Inc.
July 24, 2013
5.2.14 Function Code #509 - Protected Typed Logical Write (Two
Address Fields)
Column Parameter Description Parameter
1 Enable/Type Word 0=Disabled, 1=Continuous and 2=Conditional.
2 Virtual Database Address This parameter defines the database address of the
first data point to be associated with the command.
3 Poll Interval Minimum time in tenths of a second to wait before
polling with this command.
4 Count Number of data word values to be considered by the
function.
5 Swap Type Code Swap type code for command: 0=None, 1=Swap
words, 2=Swap words & bytes and 3=swap bytes in
each word.
6 Node Address Address of unit to reach on the data highway.
7 Slot Number Processor slot number in Control/CompactLogix rack.
Use -1 for PLC5 & SLC processors.
8 Function Code = 509 Logical Write Command
9 File Type SLC file type letter as used in file name string. Valid
values for the system are N, S, F, A, …. P1
10 File Number SLC file number to be associated with the command. P2
11 Element Number The parameter defines the element in the file where
write operation will start. P3
12 Not Used This field is not used by the command. Values entered
in this column will be ignored.
P4
This function writes one or more words of data to a PLC data table.
