MVI56-DFCM ♦ ControlLogix Platform Reference
DF1 Half/Full Duplex Master/Slave Serial Communication Module User Manual
ProSoft Technology, Inc. Page 95 of 106
September 24, 2014
Note: The Module Specific error codes (not DF1 compliant) are returned from within the module
and never returned from an attached DF1 slave device. These are error codes that are part of the
DF1 protocol or are extended codes unique to this module. The standard DF1 error codes can be
found in the DF1 Protocol and Command Set Reference Manual (Publication 1770-6.5.16) from
Rockwell Automation. The most common errors for the DF1 protocol are shown in the following
tables:
5.4.1 Local STS Error Codes
Code (Int) Code (Hex) Description
0 0x0000 Success, no error
256 0x0100 DST node is out of buffer space
512 0x0200 Cannot guarantee delivery (Link Layer)
768 0x0300 Duplicate token holder detected
1024 0x0400 Local port is disconnected
1280 0x0500 Application layer timed out waiting for response
1536 0x0600 Duplicate node detected
1792 0x0700 Station is offline
2048 0x0800 Hardware fault
5.4.2 Remote STS Error Codes
Code (Int) Code (Hex) Description
0 0x0000 Success, no error
4096 0x1000 Illegal command or format
8192 0x2000 Host has a problem and will not communicate
12288 0x3000 Remote node host is missing, disconnected or shut down
16384 0x4000 Host could not complete function due to hardware fault
20480 0x5000 Addressing problem or memory protect rungs
24576 0x6000 Function not allowed due to command protection selection
26872 0x7000 Processor is in Program mode
-32768 0x8000 Compatibility mode file missing or communication zone problem
-28672 0x9000 Remote node cannot buffer command
-24576 0xA000 Wait ACK (1775-KA buffer full)
-20480 0xB000 Remote node problem due to download
-16384 0xC000 Wait ACK (1775-KA buffer full)
-12288 0xD000 Not used
-8192 0xE000 Not used
0xF0nn Error code in the EXT STS byte (nn contains EXT error code)
