Controller Installation (Standard)
2-8 AcceleRAID 150 Installation Guide
3. Remove the AcceleRAID 150 controller from the anti-static bag as
shown in Figure 2-5.
Figure 2-5. Remove the Anti-static Bag
4. If Jumper 10 (JP10) is installed, place it on only one peg to the OFF
position, as shown in Figure 2-6, when using the standard AcceleRAID
150 configuration.
Figure 2-6. Jumper 10 (JP10) on one peg, OFF position
JP10
