Model PD6000 Analog Input Process Meter Instruction Manual
92
Display Parameter Action/Setting Description
Linear Linear Set meter for linear function and select
number of linearization points
Lit Hi
Max on little
display Assign digital input to display max on the
small display
Lit HL Max/min little
display Assign digital input to toggle max/min on the
small display
Lit Lo Min on little
display Assign digital input to display min on the
small display
Little
Little display Press Enter to assign the small display
parameter (default: engineering units)
locd Locked Enter password to unlock meter
Lt-CLr Latching-
cleared Set relay for latching operation with manual
reset only after alarm condition has cleared
mA 4-20 mA Set meter for 4-20 mA input
mAn Manual Press Enter to manually control relays or
analog output operation
mAx
Maximum Program maximum mA output allowed
mbus
Modbus Select to display Modbus input or to assign
Modbus input as the analog output source
menu Menu button Assign digital input to Menu button
min Minimum Program minimum mA output allowed
No PtS
Number of
points Set meter for 2 to 32-point linearization
O Hold Relays output
hold Assign digital input to hold all relays state
OFF
Off Disable relay and front panel status LED,
turn relays off, program off time delay
OFF 1
Off 1 Set relay 1 Off time delay (1-8)
On
On Enable fail-safe operation, turn relays on,
program on time delay
On 1 On 1 Set relay 1 On time delay (1-8)
O-rang Overrange Program mA output for display overrange
Out 1 Output 1 Program output 1 value (e.g. 4.000 mA)
