Model PD6000 Analog Input Process Meter Instruction Manual
86
Parameter Display Default Setting User Setting
Relay 3 reset point RSt 3 2.500
Relay 4 action Act 4 Automatic
Relay 4 set point Set 4 4.000
Relay 4 reset point RSt 4 3.500
Fail-safe relay 1 Fls 1 Off
Fail-safe relay 2 Fls 2 Off
Fail-safe relay 3 Fls 3 Off
Fail-safe relay 4 Fls 4 Off
On delay relay 1 On 1 0.0 sec
Off delay relay 1 Off 1 0.0 sec
On delay relay 2 On 2 0.0 sec
Off delay relay 2 Off 2 0.0 sec
On delay relay 3 On 3 0.0 sec
Off delay relay 3 Off 3 0.0 sec
On delay relay 4 On 4 0.0 sec
Off delay relay 4 Off 4 0.0 sec
Loop break relay 1 ignore Ignore
Loop break relay 2 ignore Ignore
Loop break relay 3 ignore Ignore
Loop break relay 4 ignore Ignore
Display 1 analog out Dis 1 4.000
Output 1 value Out 1 4.000 mA
Display 2 analog out Dis 2 20.000
Output 2 value Out 2 20.000 mA
Source analog output Source Process Variable
Overrange output O-rang 21.000 mA
Underrange output u-rang 3.000 mA
Loop break output break 1.000 mA
Maximum output
mAx
23.000 mA
