Model PD6000 Analog Input Process Meter Instruction Manual
89
Alphabetical List of Display Functions & Messages
Display Parameter Action/Setting Description
20 mA 20 mA output Enter mA output value read by milliamp
meter with at least 0.001 mA resolution
4 mA
4 mA output Enter mA output value read by milliamp
meter with at least 0.001 mA resolution
999999
-99999
Flashing
display Overrange condition
Underrange condition
Ack Acknowledge Acknowledge relays
Act 1 Action 1 Set relay 1 action
Alm 1 Alarm 1 Assign digital output to Alarm 1-8
Altern Alternate Set relay for pump alternation control
A-man Auto-manual Set relay for automatic & manual reset
Aout
Analog output Enter the Analog output scaling menu
Aoutpr
Analog output
programming Enter analog output programming
Auto Automatic Press Enter to set automatic operation
baud Baud rate Select baud rate
big Big display Press Enter to assign the main display pa-
rameter (default: PV)
Big Hi Max on big
display Assign digital input to display max on the
main display
Big HL
Max/min big
display Assign digital input to toggle max/min on the
main display
Big Lo Min on big
display Assign digital input to display min on the
main display
break
Loop break Set relay condition if loop break detected
bypASs
Bypass Set filter bypass value
C CAL Current
calibration Calibrate 4-20 mA current input (internal
reference source used for scaling the input)
C Hi
Current high Calibrate high current input (e.g. 20 mA)
C lo
Current low Calibrate low current input (e.g. 4 mA)
Cal
Calibrate Enter the Calibration menu
