Configuring the Serial Port
6-8 Management Setup Menu Screens
6.3 CONFIGURING THE SERIAL PORT
You can access the on-board configuration program by attaching a VT100 compatible device to the
switch’s COM port. (For more information on connecting to this port, refer to
Chapter 2 .) The
communication parameters for this port can be accessed from the Serial Port Configuration screen
(
Figure 6-6 ) shown below and described in the following table.
Figure 6-6 Serial Port Configuration Screen
Management Mode : CONSOLE MODE
Baud rate : 9600
Data bits : 8
Stop bits : 1
Parity : NONE
Time-Out (in minutes) : 10
Auto Refresh (in seconds) : 5
3583_14
